Melacoustic®Melamine Pipe Insulation

Melacoustic® melamine pipe insulation material boasts an exceptionally high porosity of 99%, which greatly extends the heat conduction path, providing excellent thermal insulation properties. Additionally, the material exhibits stable physical and chemical properties, allowing it to maintain its insulating characteristics over long periods in various environments.

Melacoustic®Melamine Pipe Insulation
滚动图
滚动图

Custom Inquiry

Name:
Company
Mailbox:
Phone:

Product Parameters

General properties

Flame Retardant
ASTM-E84●  A-level
UL94●  v0
GB/T8624●  B1
Noise Reduction Coefficient
Environmental
Asbestos●  Not detected
REACH●  Meets
ROHS●  Meets
Thermal Conductivity
TemperatureThermal conductivity
25℃●  0.034W/(M.K)
0℃●  0.028W/(M.K)
-40℃●  0.022W/(M.K)

Physical Properties

Model
Melacoustic®-FT8
DensityKG/m³●  8.5±1.5
Thicknessmm●  10~400
Tensile strengthKPa●  ≥130
Elongation at break%●  ≥15
Hardness/●  50~80
Resilience%●  ≥70
Thermal resistance℃●  (-240℃—220℃)

Recommended Size

Recommended shapes●  Recommended specifications
 Insulation pipe●  φ100*1200mm
●  φ150*1200mm
●  φ200*1200mm
●  φ250*1200mm
Roll●  T5*1250mm*20m
●  T5*1250mm*35m
* Custom sizes
