Melacoustic Insulation Foam

Melacoustic  thermal insulation Foam features an ultra-high porosity rate of over 99%, allowing it to effectively elongate the thermal conductivity path infinitely and thus possess excellent thermal insulation properties. Due to its unique three-dimensional structure, it can effectively hinder the spread of heat through convection, radiation, and conduction. Additionally, the material exhibits stable physical and chemical properties, enabling it to maintain its thermal insulation characteristics continuously in various environments over the long term. With its inherent flame retardancy and excellent secondary processing capability, the material can be applied in various forms for thermal insulation purposes in fields such as mechanical equipment, rail transportation, new energy, construction, and household appliances.

Melamine™ Insulation Foam
滚动图
滚动图

Custom Inquiry

Name:
Company
Mailbox:
Phone:

Product Parameters

General properties

Flame Retardant
GB/T8624●  B1
ASTM-E84●  A-level
UL94●  v0
EN45545●  HL3
CCAR25.856(a)●  Meets
Noise Reduction Coefficient
Environmental
ROHS●  Meets
REACH●  Meets
Asbestos●  Not detected
GB/T18580●  E1/E0
Thermal Conductivity
TemperatureThermal conductivity
25℃0.034W/(M.K)
0℃0.028W/(M.K)
-40℃0.022W/(M.K)

Physical Properties

Model
Melamine™-FT8
DensityKG/m³●  8.5±1.5
Thicknessmm●  10~400
Tensile strengthKPa●  ≥130
Elongation at break%●  ≥15
Hardness/●  50~80
Resilience%●  ≥70
Thermal resistance℃●  (-240℃—220℃)

Recommended Size

Recommended shapes●  Recommended specifications
 Insulation pipe●  φ100*1200mm
●  φ150*1200mm
●  φ200*1200mm
●  φ250*1200mm
Roll●  T5*1250mm*20m
●  T5*1250mm*35m
片材●  1250*500mm
●  1250*1250mm
●  2500*1250mm
* Custom sizes
