Melacoustic Building Sound Absorbing and Insulating Board

Melacoustic architectural sound-absorbing and soundproofing panels, composed of lightweight flame-retardant porous melamine material and various damping combinations, work simultaneously to absorb and isolate sound. They effectively capture sound waves above 200Hz with a capture rate of over 95%, and also provide good blocking effects for low-frequency sounds at 200Hz. With exceptional secondary processing capabilities, these panels can be applied in various forms for acoustic treatment in venues such as hotels, schools, hospitals, sports arenas, and auditoriums, as well as for noise reduction in factory equipment and air conditioning ducts.

Melamine™ Building Sound Absorbing and Insulating Board
滚动图
滚动图
滚动图
滚动图

Custom Inquiry

Name:
Company
Mailbox:
Phone:

Product Parameters

General properties

Flame Retardant
GB/T8624  B1
ASTM-E84●  A-level
UL94  v0
Noise Reduction Coefficient
20mm  0.65
30mm●  0.75
40mm  0.8
50mm●  0.9
80mm●  0.95
Environmental
ROHS  Meets
REACH●  Meets
GB/T18580  E1/E0
Thermal Conductivity
Soundproof property(dB)
22mm23
33mm26

Physical Properties

Model
Melamine™-FT8
DensityKG/m³  8.5±1.5
Thicknessmm  10~400
Tensile strengthKPa  ≥130
Elongation at break%  ≥15
Hardness/  50~80
Resilience%  ≥70
Thermal resistance  (-240℃—220℃)

Recommended Size

  1250*500mm

  1250*1250mm

  2500*1250mm
  Custom sizes
